VA04-36-340010 125A circuit breaker

The circuit breakers BA 04-36 - 340010 at 125 A 660 50 Hz air. We sell automatic circuit breakers BA 04-36 340010 125А, ВА04-36-340010 for 125А, ВА04-36 340010 125А, ВА-04-36-340010 125А and others, in a molded plastic case and in different versions. The price in Ukraine for the BA04-36 125A automatic circuit breakers is the best from RPE RIMK LLC. Imagine the popular types: BA04-36-341810 125A, BA04-36-341110 125A, BA04-36-341830 125A, BA04-36-341130 125A, BA04-36-840010 125A, BA04-36-331810 125A, BA04-36- 330010 125A, BA0436 340010 125A. We give a guarantee for BA 04-36 125A circuit breakers 3 years! There are available circuit breakers BA0436 125A, BA 0436 125A, BA-0436 125A, BA 04-36 125A, BA-04-36 125A ready for shipment. Mass BA 04-36-340010 125А - 2.3 kg, not more. Export is possible. Deliveries of BA0436-125A are carried out by shipment at own expense, or transport companies. Manufacturer BA0436 - CONTACTOR and KEAZ.

Technical characteristics of switches BA 04-36 340010 125А:

1. Rated current 125 A.

2. The number of poles 3, 2

3. Rated current of the warm release BA 0436 - 125A

4. The setting for the initial tripping current in the zone of overload currents, which is a multiple of the rated current of the thermal release - 1.25.

5. The settings for the response current of electromagnetic maximum current release from 200A to 2000A.

6. The wear resistance of switches - BO 3000, the number of BO cycles under load is 1000.

Technical description BA04-36: Circuit breakers BA04-36 for rated current BA 04-36 125А, 200А, 160А, 250А, 100А, 80А, 63А, 40А, 31,5А, 25А and others are manufactured with thermal and electromagnetic releasers. Automatic switches BA-04-36, BA 04 36- 3-pole, are made for alternating current, and automatic switches BA-04-36, BA 04-36 2-pole are manufactured for direct and alternating current 50 Hz.

BA 04-36 automatic circuit breakers are designed for switching current in normal mode and protection for overloads of unacceptable duration, for short circuits, as well as for infrequent, up to 25 times a day, quick disconnection of electric circuits with a rated voltage up to 660 V AC of frequency 50 and 60 Hz and up to 440 V DC. AC circuit breakers can also be used to protect infrequent and direct start-ups of asynchronous electric motors in the AC-3 application category. VA 04 36 circuit breakers are available with thermal and electromagnetic maximum releases, only with electromagnetic maximum current releases and without maximum current releases. Circuit breakers can be equipped with a zero voltage release, shunt release, free contacts and an electromagnetic drive. Automatic are available in fixed version - front, rear and combined connection and in retractable design
